Stationary square bale wrapper
G3010 Q Farmer | Square bale wrapper
The stationary square bale wrapper is the ideal machine for single-person operation. The easy-to-operate STANDARD control with wireless operation allows the operator to combine cycles with perfect ease. Thanks to its compact design, the G3010 Q Farmer stationary square bale wrapper can be transported using almost any tractor.
Highlights
Secure bale Guiding
The roller tubes arranged on both sides are connected to each other by control rods. This results in forced control which, in conjunction with the conveyor belt, produces a clamping effect on the bale. The wrapper is able to guide the bale securely even with rectangular bale dimensions. A quick adjustment can adapt the belt length to different bale dimensions.
Control Standard
A genuine highlight is the user-friendly and easy-to-use program control STANDARD.
Continuous belt
The wide, continuous belt guarantees uniform wrapping of each and every bale – even if it is misshapen.
engine
An 8.2 kW gasoline engine with a battery, alternator, electric starter, and hydraulic system is available as an option.
Reermann Agrarservice in action with two G-1 F125 Kombis
A powerful one-two punch in forage harvesting: The Reermann Agrarservice contracting firm from Brilon serves its customers with two GÖWEIL baler-wrapper combinations. Although there is a wide selection of round balers available, the service provider deliberately chose the blue machines from Austria. In this video, we’ll take a look with you at how this came about and what the technology is capable of under these demanding, continuous operating conditions. Come along and join the forage harvesting pros from the Sauerland region as they go about their work!
“We decided to go with the GÖWEIL wrapper again, and this time with the baler built right in – which, from a technical standpoint, totally blew us away!”
Stefan Reermann
Agricultural Service Specialist from the Sauerland Region
Video of the G3010 Q
Basic Model
(without hydraulic oil) - WITH EU type-approval
Single wrapping arm
Hydraulically tilting wrapping table with mechanical belt length adjustment
Bale deposit to the left or right
Wide, continuous bale conveyor belt with belt guide and 2 bale guide rollers
Film pre-stretcher combined
For film widths between 500 mm and 750 mm (20” and 30”); the overlap can be adjusted as well
Film cutter precision cut
Hydraulically adjustable lift axle
Removable, hydraulic articulated drawbar
Storage for 4 rolls of film
Tires 300/80-15.3 AW
1-cylinder Honda gasoline engine (without hydraulic oil)
8.2 kW gasoline engine with battery Electric starter Return filter 30 l hydraulic oil tank
Feed rate shut-off valve
This ensures that the film will overlap accurately for rectangular bales
LED Light and indicator system
LED work lights
Program control STANDARD with radio remote control
The cycles “wrapping process” and “film-holding and cutting” start automatically
, while “bale drop” starts at the push of a button.
Technical data
(Basic model)
| Weight | 1,670 kg |
| Length | 5,260 mm |
| Width | 1,950 mm |
| Height | 3,140 mm (10’ 6”) (with the lift axle extended) |
| For all bale dimensions: | from 0.80 x 0.50 to 1.20 x 1.40 m |
| Bale length: | from 0.80 up to 1.60 m |
| Round bale diameter | 0.90 – 1.50 m (36” – 60”) |
| Oil requirement | Self-sufficient oil supply |
| Bale weight round / square: | max. 1,800 / 1,000 kg (max. 4,000 / 3,300 lbs) |
Required connections
| 7-pin power outlet for the entire lighting system (excluding work lights) |
Additional equipment
Tires 380/55-17 AW
Width altered to 2,130 mm (7’)
Film monitoring
Stops the wrapping process if film tears or runs out
Additional bale guide roller
10 l (2.5 gal) spare fuel can including bracket
Drawbar eye types
J, K, L (specify when ordering)
FAQ - Frequently asked questions
Which tires are available for the G5012?
Basic model tires: 380/55-17 AW
tires Additional equipment: 480/45-17 AW
Does the G5012 wrapping machine come with a bale tipper? And how does this work?
The bale tipper is available as additional equipment. When the wrapping process is complete, the bale is positioned on its right front side with the direction of travel.
What is the wrapping time with the twin wrapping arm of the G5012?
The duration depends on the bale size and the number of film layers.
How do you control the G5012 wrapping machine?
The "bale pick-up" function is performed manually using the electronic joystick. The cycles “wrapping process” and “film-holding and cutting” start automatically, while “bale drop” starts at the push of a button. The program control STANDARD with wireless operation is included in the scope of delivery.
